The 12" tall Drift Solar 4-pipe fence-style snow retention system is designed specifically for snow retention below solar panel arrays.
These aluminum 4-pipe fence-style brackets are for use on new and existing roofs where snow is being retained on or below solar panels. They are bolted to the roof support structure flush at the eave with the tubing side facing down-slope (reversed installation compared to other Drift Series snow fence installations) creating a "catch basin" for the snow coming off the solar panels.
Roof Mounting Method:
- Must be bolted directly to roof support structure (rafters/trusses)
- Requires five (5) #15 x 2.5" CTX lag screws when fastening into wood
- Customer must source their own 1/2" x 3.5" lag bolts (five per bracket) when fastening into metal support structure
- Ice Screen must be installed to impede the movement of snow between the tubing.
System components sold individually, assembled to meet the specifications of your roof installation's snow retention needs.
Additional Information:
Job Specific snow retention layouts are available from Rocky Mountain Snow Guards, Inc. These are provided at no charge. Snow Guard Depot recommends obtaining a job specific layout for all snow retention projects. Without a job specific layout, Snow Guard Depot cannot guarantee that snow guards purchased will perform effectively. Snow retention layouts can be obtained by contacting Rocky Mountain Snow Guards here.
